Usage:
1. Tea bottles inverse sterilizer machine is mainly used after hot filling fruit juice and tea in PET bottle to sterilize PET bottle mouth and inside surface of caps, which haven't been disinfected by high temperature.When working, it turn up the bottle in the angle 96 or 110 degree in the process of transporting bottle, and the beverage sterilize to the cap inside with its high temperature (higher than 80ºC) after filling.
2. It mainly consists of chief conveying chain system, surport, bottle reversing chain system, bottle reversing guiding rod and bottle repositioning rod.
3. It uses inner thermal medium to disinfect bottle mouth and caps without any other heat source, so it can save energy.
4. The machine is fully made of SUS304 stainless steel, elegant in appearance more convient in operation
5.bottle sterilizer is used for sterilizing to the caps inside after filling. The sterilizing time can be adjusted in the scope of 30-40 seconds as requirement. It adopts imported stainless steel chain and enduring high temperature plastic chain board. With the excellent features of compacted structure, convenient operation, and saving energy, this kind of machine is the best choice for fruit juice, tea drink hot filling cap sterilization.
Matching cooling warming tunnel
After sale service:
1. Delivery time: one month after get deposit
2. Guarantee: one year under normal operation
3. as capacity different inverse sterilizer length and width different.
4. suit pet bottle juice milk hot filling bottle cap sterilizer
