The1year
- Model NO.：
- XJW65x12D
- Certification：
- CE, ISO
Usage:
Silicone rubber extrusion and vulcanization Production linecan make variours silicone cable or silicone profiles such as tubes. Strips and sealing.
Product Description:
cold feeding silicone rubber extruder : Single screw cold-feed silicone rubber extruder
types : Screw diameter including150mm, 120mm, 90mm, 75mm, 65mm,50 mm
Feeding type : Cold rubber compound
single screwmaterial :38CrMoAlA
Main technical parameters:
| Model | Diameter | L/D | Highest ScrewRotationalSpeed | Motor Power | Produce Capacity |
| Unit | mm | L/D | r/min | Kw | Kg/h |
| XJW-50 | Ø 50 | 12:1 | 70 | 12 | 50 |
| XJW-65 | Ø 65 | 12:1 | 70 | 22 | 80 |
| XJW-75 | Ø 75 | 12:1 | 65 | 30 | 130 |
| XJW-90 | Ø 90 | 12:1 | 60 | 45 | 230 |
| Ø 90 | 14:1 | 60 | 55 | 230 | |
| XJW-120 | Ø 120 | 12:1 | 55 | 75 | 500 |
| Ø 120 | 14:1 | 55 | 90 | 500 | |
| XJW-150 | Ø 150 | 12:1 | 45 | 132 | 800 |
| Ø 150 | 14:1 | 45 | 160 | 800 |
Please you can choose suitable model according to your actual production.
Product Pictures:
