Introduction of Small Grinder
The small feed grinding machine, also called small hammer mill or feed crusher is a machine specializing in crushing materials by the collision between the high-speed hammer and materials. For realizing different processing effects, you just need to change the screen with different size holes. It can be used independently or be the first part of fish feed pellet production line.
Main Features of the Small feed grinding mill
1. Cheap Price. Because of low price and high efficiency, this small grinding machine is the best choice for the farm owner, small and middle size feeding factory or for family use.
2. Easy operation and low energy consumption. This will greatly save your money and time.
3. Wide application. It can process both agricultural materials and pharmaceutical &industrial materials such as corn stalk, peanut shell, dry grass and Chinese medicine crops, coal residue,etc.
4. Simple structure for easy daily maintenance. Good maintenance contributes to long service life of a machine.
5. Core part is made of alloy steel to ensure long service life and excellent processing effect.
Main Parameters of Small Feed grinding mill
| Model | Power (kw) | Capacity (kg/h) | Dimension (mm) | Weight (kg) |
| HM320 | 5.5-7.5 | 200-300 | 1500*800*1050 | 220 |
| HM420 | 7.5-11 | 250-500 | 1500*930*1250 | 230 |
| HM500 | 11-15 | 400-800 | 1600*1050*1300 | 320 |
We also provide accessory machinery and parts for the feed hammer mill machine, such as rotary feeder, buffering hopper and bin, pluse dust control system, etc. We design the complete feed plant, feed crushing process for small scale or medium, large scale feed factory.
Detailed introduction of the fish feed extruder machine1. Fish feed machine, also known as fish feed extruder, is used to process various kinds of grains into high-grade aquatic feed pellets for fish, crab, catfish, shrimps, etc.
2. This fish feed machine has gained popularity in fish farmers.
3. This machine is suitable for small and medium aquatic farm or feed pellets processing factory.
4. Compared with buying fish feed, making your own fish feed pellets by the floating and sinking fish feed extruder is really cost effective.
5. Aquaculture feed pellets have wonderful taste and high nutrition.
6. The size of pellet aquaculture feed made by this fish feed extruder can be adjusted according to your need.
Features of the fish feed extruder machine.
1. Novel design, high output and stable performance.
2. Main parts are made of special alloy material after heat treatment.
3. High wear resistant degree and long service time.
4. This dry type fish feed machine is suitable for small fish feed plant and professional farmers.
5. Final processed aquatic feed pellets have unique taste and high nutritious.
6. Low energy cost, high capacity, easy to maintain.
7. Diameters and shapes of fish pellets can be adjusted by choosing different molds.
8. Salmonellas and bacterial infections can be killed by high temperature and high pressure process.
9. Feed pellets produced by this fish feed machine of puffing type, thus making it more easily to digest for fishes.
Specification of fish feed extruder
| Model | Capacity | Main power | Feeding power | Screw diameter | Cutting power |
| DGP50 | 60-80kg/h | 11kw | 0.4kw | φ50mm | 0.4kw |
| DGP60 | 100-150kg/h | 15kw | 0.4kw | φ60mm | 0.4kw |
| DGP70 | 180-250kg/h | 18.5kw | 0.4kw | φ70mm | 0.4kw |
| DGP80 | 300-350kg/h | 22kw | 0.4kw | φ80mm | 0.6kw |
| DGP90 | 400-450kg/h | 37kw | 0.4kw | φ90mm | 1.5kw |
| DGP120 | 0.5-0.7t/h | 55kw | 0.4kw | φ120mm | 2.2kw |
| DGP135 | 0.8-1.0t/h | 75kw | 0.4kw | φ133mm | 2.2kw |
| DGP160 | 1.2-1.5t/h | 90kw | 0.75-1.1kw | φ155mm | 3.0kw |
| DGP200 | 1.8-2.0t/h | 132kw | 1.5kw | φ195mm | 3.0-4.0kw |
Fish feed and shrimp feed Aquatic feed line from China process:
Description of the Fish feed and shrimp feed Aquatic feed line from China
| No. | Process | Machine | Description |
| 1 | Crushing | Crusher/Hammer mill | To crush the raw materials such as grains into flour/powder |
| 2 | Mixing | Mixer | To mix different flour materials together and evenly |
| 3 | Extruding and pelleting | Fish Feed Extruder | To make fish feed pellet, the material is processed by high temperature and pressure and pelletized into round pellets, suitable for feeding fish, we could produce bothfloating fish feed and sinking fish feed. |
| 4 | Drying | Dryer | Todry the fish feed pellets coming from the extruder |
| 5 | Cooling | Contraflow Cooler | To cool the fish feed pellets, the fish feed pellets could be stored for along time. |
| 6 | Flavoring | Rotary flavoring machine | To seasoning the fish feed, spray oil and other liquid additives on the surface of fish feed pellets, make the feed more delicious. |
| 7 | Packaging | Automatic Packaging machine | To pack fish feed pellets into bags, easy for store, transportation and for sale in the market. |
Packing and shipping
The feed hammer grinder mill would be covered by plastic, and then packed in standard ply wooden package for exporting.
Our Services
| 1 | We provide 1year guarantee with life-time service. |
| 2 | We provide English manual and video for operation |
| 3 | If required, we could send technicians for installation and commissioning, training. |
| 4 | Any problem in operation or others about the machine, you can contact with us we will give solution in 24-48 hours. If big problem, we can send technician to customer's local place. |
