ZH Centrifugal Slurry Pump

Price:100.00

Minimum order:1 件Stock500 件

Total:
500 件
Brand:
CNZKING
Area:
HEBEI
Delivery time:
From the date of payment by the buyer7internal delivery

Business card

  • Corporate nameShijiazhuang Zhongqiang Industrial Slurry Pump Co.,Ltd.
  • Contacts耿莎莎(Ms.)
  • Telephone
  • Mobile
  • AddressRoom 521, Huashan Business, No.111 Zhufeng Street, High-tech Zone,Shijiazhuang,Hebei,China
Popular goods
  • 1
  • 2
  • 3
Recommend

Desulphurization Pum

$1000.00/件

Slurry Pump 450MSR

Discuss

ZH Centrifugal Slurr

$100.00/件

Heavy Duty Metal Slu

$1000.00/件

Corrosion Resistant

$1000.00/件

Rubber Lined Slurry

$1000.00/件

Store information

Area:HEBEI

Level:VIP memberThe1year

Authentication:

Paid:0.00 bond

My Medal: [archives]

Customer service:

Business card

【warm tips】please explain what you saw us atAfrican-MachineThank you
Product details

Brand: ZKING
Certificate: ISO/CE
Place of Origin: Hebei,China
Minimum Order Quantity: 1set
Delivery Time: 10-14 working days
Payment Terms: T/T, Western Union
Supply Ability: 30 Sets per Month
Packaging Details: Wooden crate


Specifications:

● Flow rate :180-720m3/hr
 ● Head H(m): 10-60
 ● Speed: 500-1140rpm
 ● Efficiency:Max. 72%
 ● Materials: Impeller A05
 ● Impeller:5-Vane Closed Type, F6147A05
 ● Vane Diameter(mm): 510mm
 ● Power: Max 120Kw
 ● Color: Depend on customers’ requirements
 ● Weight: 1478KG
 ● NPSH (m): 2-10
 ● Warranty: 1 year Warranty (except wet-end parts)



Introduction:


 1. ZKING Slurry pumps are designed with double casing, wet-end parts, and rotary parts. Wet-end parts includes volute, impeller, front and back liner. The rotary parts includes the bearing assembly, which are composed of bearing housing, shaft, bearings etc.
 2. This is a heavy duty slurry pump that is extremely durable and easy to maintain. It is highly efficient and corrosion and erosion resistant.
 It has a long wear life and is extremely cost efficient. The use of effective liners make this pump easy to maintain.
 The pump’s many benefits include the bearing assembly, cover/frame plates, suction cover, liners, the impeller, and it has a one piece base.
 3. ZH-150E is a slurry pump with discharge size 4 inch, and it is almost the best popular pump at ZKING.
 4. ZH-150E is mostly sold to our customers from Russia, Holland, Italy and other Eastern and Western European countries. ZKING will always be your reliable partner for quality slurry pumps and pump spare parts.
 5. These pumps are characterized by long life, efficient operation and easy maintenance with its low cost.
 Pumps are available with either a rubber or a metal lining of abrasive – and corrosion resistant materials. Used bearings for heavy duty, with the increased load on them.
 6. Application of ZKING slurry pumps: mining and processing, mining and metallurgical plants, power plants, cement production enterprises, and diamond-gold mines, technological crushing line, mineral processing, etc.



Specifications:

TypeSizeframeImpeller: F6147A05Shaft Seal Typeframe Rating(kw)Normal Max Speed(r/min)Max Passage Size(mm)
ZH150E5 Closed Type metal Vans, Diameter: 510mmGland Packing, Expeller, Mechanical Seal120114063



 ZH Series metal Slurry Pump Specifications
Pump
       Model
S×D
       (inch)
Allowable
       Max. Power (kw)
MaterialClear Water PerformanceImpellerPricing
Capacity QHead
       H(m)
Speed
       n(r/min)
Max.Eff.
       η%
NPSH
       (m)
No. of
       Vanes
Vane Dia.
       (mm)
Weight
       (kg)
Impellerm3/hl/s
ZH/25B1.5×115metal
       (A05)
12.6-28.83.5-86-681200-3800402-4515291
ZH/40B2×1.51532.4-729-206-581200-3200453.5-8184118
ZH/50C3×23039.6-86.411-2412-641300-2700554-6214191
ZH/75C4×33086.4-19824-559-521000-2200714-6245263
ZH/75D4×360245363
ZH/100D6×460162-36045-10012-56800-1550655-8365626
ZH/100E6×4120365728
ZH/150E8×6120360-828100-23010-61500-1140722-95101473
ZH/150F8×62605101496
ZH/150R8×63005101655
ZH/200F10×8260612-1368170-38011-61400-850714-106863193
ZH/200ST10×8560612-1368170-38011-61400-850714-106863750
ZH/250F12×10260936-1980260-5507-68300-8008267623760
ZH/250ST12×10560936-1980260-5507-68300-8008267624318
ZH/300ST14×125601260-2772350-77013-63300-600773-109656409
ZH/350TU16×1412001368-3060380-85011-63250-550794-10106710000



Material: High Chrome Alloy A05


Material Chemical Requirements, Weight%

DescriptionMaterial NameCMnSiNiCrMoCuPVSDescriptionHardness
A05


ASTM A532

Ultrachrome2.920.980.540.827≤0.80.0620.05127% Cr Erosion Resistant White Iron58-62HRC



Construction of ZH Slurry Pumps:

Typical Applications:

 Ash Handling
 Cyclone Feeds
 Pulp and Paper
 Abrasive Slurries
 Coal Preparation
 Mineral Processing
 Aggregate Processing
 Mining Industries



The primary applications for the ZKING ZH/150E metal slurry pumps are mill discharge, crusher slurry, sand and aggregate or any coarse solids or other severe, abrasive slurries especially in te copper, gold, iron ore, lead-zinc, coal or phosphate plants.

The most dramatic savings will be in these applications, though savings will also be realized on find solids, like fine sand recovery or kaolin. The key advantage of the ZH metal slurry pumps is the 10% to 30% lower power, long even wear life and less pump downtime, which results in lowe cost-per-ton pumped, along with better cyclone separation.



ZKING SH Slurry pumps are designed for the toughest slurry applications
