The1year
300KW 375KVA diesel generator
1000KW 1250KVA generator
16KW 20KVA generator hot sale
1000KW 1250KVA generator price
24KW 30KVA generator ricardo
350KW 437KVA diesel generato
400KW 500KVA diesel generator
120KW 150KVA generator diesel
400KW 500KVA generator diesel
700KW 875KVA diesel generator
- power：
- 1200KW 1500KVA
- Frequency/voltage：
- 50HZ 60HZ 380V-480V
- Options：
- open/silent/ATS/trailer/closed/soundproof/canopy/
Alternator type | Pure copper brushless |
Connection mode | Three phase four wire |
normal frequency | 50/60HZ |
Certificate | CE/ISO9001/ISO14001 |
Warranty time | 12 Months/1000 Hours |
Cooling System | Water-Cooled |
Color | Customers' Requirement |
Starting method | 24V DC Electric Start |
Control panel | Standard Panel |
Optional | Automatic transfer switch |
Power factor (PF) | COSΦ=0.8（lag） |
Output voltage(OV） | 400V/440V/230V/220V/110V |
Diesel oil type | (standard) 0 × light diesel (normal temperature) |
Steady state voltage regulation rate (%) | ≤±1 |
Voltage fluctuation rate(%) | ≤±0.5 |
Transient voltage regulation(%) | ＋20～－15 |
Voltage settling time(S) | ≤1 |
Steady-state frequency control | ≤±1 |
Frequency jitter(%) | ≤±0.5 |
Transient frequency fluctuation(%) | ＋10～－7 |
Frequency stabilization time(s) | ≤3 |
Rated speed | 1500/1800rpm |
