Impeller feeder

Applicable temperature：

≤40℃

Suitable medium：

Dry dust particles

The GLJNY-3 low-temperature section steel impeller feeder is suitable for the industrial transportation and distribution system of power plant, cement plant, chemical plant and other industries, and can be used as a gas-lock or a quantitative feeding system for conveying and drying powdery materials, and can also be used for ash discharging under the ash hopper of the dust remover and the air preheater, convenient operation and maintenance, and is an ideal accessory for conveying, discharging and proportioning system

The steel impeller feeder is composed of a rotating impeller with a grid chamber, a machine body, a novel cycloid pin wheel speed reduction motor and the like, and has the advantages of small volume, reliable work, good sealing and good wear resistance. when the impeller is driven in the machine body by the transmission mechanism, the powder material falling from the upper separator (or hopper) enters the impeller chamber from the feeding port, and is sent to the discharge port to be discharged along with the rotation of the impeller,

The temperature of the material conveyed by the steel impeller feeder can reach 280 degrees, and both ends of the bearing are separated from the impeller to prevent the ultrafine powder from coming into contact with the bearing. The temperature of the conveying material of the high-temperature resistant rigid impeller feeder can reach 500 degrees, the chain wheel is connected, and the speed reducer and the discharger shell have a certain distance. The rigid impeller feeder is commonly used in the pneumatic output system, and the rigid impeller feeder can be uniformly and continuously fed to the conveying pipe for the pressure output system or the negative pressure output system, so as to ensure that the air and the solid in the pneumatic output pipe are relatively stable, so that the pneumatic conveying can work normally, at the same time, the upper and lower air pressure partitions of the rigid impeller feeder can be separated to play a role of locking air,

The GLJNY-3 low-temperature profile impeller feeder is widely used in dry and small granular non-viscous materials. such as raw meal powder, cement, dry slag, coal powder, fly ash and the like, has the advantages of compact structure, small volume and good sealing performance,

The steel impeller feeder is mainly divided into a low-temperature section steel impeller feeder, a steel impeller feeder, and the like, and the user can select according to the model
