The feed pellet mill, also known as animal feed pellet mill or chicken feed pellet mill, belongs to feed processing machines. It directly presses corn, soybean meal, straw, grass, rice husk, and so on into granules diet. Thus the it is widely used in aquaculture, animal feed processing plants, and poultry livestock farms. A variety of animal feed pellet mills are classified on the basis of different appearance and modes of production, in which flat die feed pellet mill and ring die feed pellet mill are the most popular ones. If you need a animal pellet mill with a capacity above 800KG/H, much more wear-resistant, and less maintenance, you may choose a ring die one, but it usually has a higher price than flat die ones.
| ▸Overview of ABC Machinery ABC Machinery SBPM Ring Die Animal Feed Plant |
▮Technical parameter of SBPM animal feed plant
| Model No. | Main motor power | Capacity (t/h) | Ring die inner diameter (mm) | Feeder power (kw) | Conditioner motor power (kw) | Size (mm) | Weight (kg) |
| SBPM25 | 22kw | 1-2 | 250 | 0.75 | 1.1 | 1750×650×1750 | 800 |
| SBPM32 | 22kw×2 | 2-5 | 320 | 0.75 | 2.2 | 1900×1800×1650 | 2000 |
| SBPM35 | 30kw×2 | 3-7 | 350 | 0.75 | 2.2 | 2100×2000×1850 | 2400 |
| SBPM40 | 45kw×2 | 4-10 | 400 | 1.5 | 4 | 2200×2000×2150 | 2900 |
| SBPM45 | 55kw×2 | 6-15 | 450 | 1.5 | 4 | 2300×2350×2150 | 3500 |
▮Advantageous features of SBPM feed pellet mill
★ Simple all stainless steel structure, small area occupation, and low noise;
★ Wide adaptability, able to produce chicken feed, duck feed, fish feed, and so on, produce higher economic benefit than mixed powder feed;
★ With dry processing technology, the feed pellets produced features in high hardness, smooth surface, and internal curing, which will improve animal's digestion and absorption of nutrients;
★ The forming process of pellets kills all kinds of parasite eggs and other pathogenic microorganisms, thus reducing the variety of insects and diseases of the digestive system.
Contact Now for Catalogs & Best Price!
| ▸Wide Application of ABC Machinery SBPM Ring Die Animal Pellet Mill |
Target User: Individuals, feed processing factory or feed mill, farm, hennery.
Application: Making animal feed pellets for various kinds of poultry and livestock, including chicken, duck, rabbits, cattle, horse and sheep, etc.
Contact Now for Catalogs & Best Price!
| ▸Highlights of ABC Machinery SBPM Ring Die Feed Pellet Mill |
★ The feeder of our ring die type animal feed plant is equipped with imported original inverter controller, feeding evenly and accurately.
★ The conditioner of this feed pellet mill is all made of stainless steel to ensure it will not deteriorate in the steam environment for a long time. It is also designed with an inspection door which is provided for easy cleaning and maintenance. During the conditioning process, the feed and steam are in full contact and the feed has a higher curing degree, which is conducive to the production of high-quality animal feed pellets.
★ The feed port of this animal feed plant is designed with a deflector that can control the flow direction of the materials (into the pelletizing chamber or discharged directly from the bottom). It is convenient to avoid the materials of the wrong ratio go into the pelletizing system.
★ The transmission belt is made of a high-strength SPB V-belt, featured stable and reliable transmission, and low noise.
★ The ring die of this animal feed plant is also made of 100% stainless steel, making it more durable. There is a variety of apertures for your choice (φ1.5mm~φ12mm), and the compression ratio is customized designed based on your specific raw materials;
★ Quick-release hoop ring die design, which is more convenient to replace and also highly improves the production efficiency;
★ One-piece spindle for easy disassembly and good mechanical performance.
★ Reasonable lubrication system design (spindle, press roller): The oil filling hole is specially designed to achieve refueling without stopping the machine.
