Hydraulic Rubber Hose SAE100 R2

SAE100 R2 steel wire reinforced hydraulic hose is suitable for delivering petroleum-base hydraulic oils thanks to its oil resistant tube. Besides, it can convey the oils without producing excessive heat and leak. It mainly serves in some mobile equipment, such as farm tractor, dump truck and in-plant hydraulic equipment. It is composed of three parts: tube, reinforce and cover. The tube is made from oil resistant synthetic rubber. So it is mainly to transfer oils. The reinforce absorbs two layers of high tensile braided steel wires. Thus the hose have solid structure and resistant to high pressure. Therefore, it has excellent performance in high pressure working environment. While the cover absorbs high quality synthetic rubber, which is resistant to weather, ozone, corrosion, abrasion, aging, sunlight and cut. Therefore, the hose has longer service life as a result.

Hydraulic Rubber Hose SAE100 R2 Is Recommended For:

High-pressure hydraulic lines. It exceeds the standard of SAE 100 R2 AT and EN853 2SN.

Application:

For high pressure hydraulic systems in industry and agriculture.

INNER TUBE: oil resistant NBR

REINFORCEMENT: two layers of steel wire braided

COVER: oil and weather resistant synthetic rubber

Working Temperature: -104℉ to +212℉ (-40℃ to +100℃)

SURFACE: wrapped or smooth surface
