- 产量：
- 200kg/h，500kg/h，1T/H,2T/H,5T/H
Turnkey project solution for cashew nut processing line /cashew nut processing machine cost/cashew nut production line
Process of Cashew nut processing plant/cashew nuts production line:
Sorting machine----Steam&Cooking machine---Natural Cooling---Automatic Cashew Nut Shelling Line for Hard Shell-Conveying ---Shell & kernel Sieving machine-----Drying---Humidifier---Automatic Soft Skin Peeling Machine-Cashew Nut-Roaster(Baking to Various Taste Cashew Nut Product)
Here is the detailed introduction of cashew processing plant working flow:
1) Cashew nut cleaning machine: clean the raw cashew nut.
2) Cashew nut grading machine: separate the cashew into several grades.
3) Cashew nut steam cooker: boil the cashew by electricity or gas so that you can shell the cashew easily.
4) Cashew nut cooler machine: make the boiled cashew nuts cool.
5) Cashew nut shelling machine: shelling the cashew.
6) Cashew nut cashew nut separator: separate the cashew nut shell and kernel.
7) Cashew nut dryer machine: dry the kernel so that you can peel the kernel easily.
8) Cashew nut peeling machine: peel the kernel and then get the clear cashew nut kernel.
9) Cashew nut sorting machine: separate the nuts into service grades.
10) Cashew nut roasting machine: you can roast the kernel.you also can use the conveyor belt type dryer to roast the kernels. (Optional)
11) Cashew nut packing machine: pack the kernel into small bags or vacuum bags . (Optional)
Specification of Automatic Raw Cashew Nut Production Line
Item | Specification | Quantity |
Hoist | Carbon steel material Size:4.5*0.51*0.5m Power:0.75kw | 1set |
Automatic Cashew nut shelling machine group (include Sub-hopper) | Single machine size: 1.4*1.05*1.3m Single machine weight:about 300KG Capacity:100--170KG Control way:Button control Motor:0.75kw Voltage:380v/50HZ Shell rate:90--95% Un-shell rate:3% Broken rate:<5-10% | 4sets
Total capacity reach:600--800kg/h |
Shell and Kernel Sieving machine | Size:5*0.5*0.8m (the machine part be made of stainless steel which will touch cashew) Power:1.5kw Voltage:380v/50hz | 2 sets |
Wind classifier
| Size:1.5*0.7*2.5m Fan Power:2.2kw /380v /50hz | 3sets |
Wind lift transmission material | Size:1.5*0.6m Height be customized based on machine Fan power:2.2kw/ 380v /50hz | 4 sets |
Centrifuge sieving machine | Size:3*0.7*1.5m Fan Power:2.2kw Motor:0.75kw 380v /50hz | 2sets |
Shell split separator Secondary separation | Motor:1.1kw Voltage:380v/50hz Size:2.3*0.8*1.6m Capacity:300--400kg/h Weight:180kg Roll gap adjustable | 1set |
the whole line can be designed according to customer's request.
