200TPD Millet Machine

200TPD Millet Processing Machine Millet Milling Machine

200TPD Millet Processing Machine Millet Milling Machine Technology Flow:

Millet cleaning---stoner---hulling mill---grading sieve---peeling off------polishing

---grading---color sorting---packing.

1. Bucket Elevator is mainly used to transport millet in complete processing line.

2. Vibrating screen is specially used for separating the impurities from millet.

3. After cleaning, millet will be transported into Proportion Stoner machine to

    separate the stone from the millet.

4. Next, the millet into the Hulling Machine to remove the shell.It can separate

    the shell from the paddy husk mixture through the suction effect.

5. The millet that has removed the shell will be into the Iron Polishing Machine.

    The machine is mainly used for  cleaning the millet to make them look brightly.

     It is one of the key processing millet.

6. Suction Separator will separate the low gravity impurities(such as hull, dust etc.)

    from the millet.

7. Out from the suction separator ,the millet into the Color Sorter to get more high

    quality millet,  white millet and break millet will be passed.

8. Last, high quality millet we need will be packed through the Automatic Packaging

   Scales.

Main production index:

1. Production capacity: 20-500t millet/24hours

2. Products structure and yield rate:

    net millet yield rate: 70-75%；

    damage rate ：1%；

    skin and husk rate：25-30%

    Millet processing plant processing capacity: 20t-500t

Technical Parameter:
