Brand:BIAOHUI
Deliver:In 3 days
Inquiry
Features:
• Gas production equipment for general industrial engineering.
• For the delivery of compressed air in garages and service stations.
• For automated machinery and power station equipment.
• Pneumatic equipment, body nail gun.
• Can be used for fire protection.
• Passed ROHS, PAHS and other testing.
• UV protection, sun protection.
 INCH | I.D. | O.D. | Length M/ROLL |
Bar |
Bar | g/m |
At23℃ | ||||||
1/4” | 6.5 | 12 | 100 | 20 | 80 | 100 |
1/4” | 6.5 | 12.5 | 100 | 30 | 95 | 115 |
5/16" | 8.5 | 14 | 100 | 20 | 80 | 130 |
5/16" | 8.5 | 14.5 | 100 | 30 | 90 | 140 |
3/8" | 10 | 16 | 100 | 20 | 80 | 160 |
1/2" | 13 | 20 | 50 | 20 | 75 | 240 |
5/8" | 16 | 25 | 50 | 20 | 60 | 380 |
3/4" | 19 | 28.5 | 50 | 20 | 50 | 460 |
1" | 25 | 34.5 | 50 | 15 | 45 | 580 |
1-1/4" | 32 | 44 | 40 | 15 | 45 | 940 |
1-1/2" | 38 | 50 | 40 | 15 | 40 | 1085 |
2" | 50 | 64 | 40 | 15 | 30 | 1640 |
