Features:
• Agriculture, industrial water supply, gas, oil, etc.
• Mine, engineering transport solid particles, pulp, etc.
• Good weather resistance, strong negative pressure resistance, small bending radius and wear resistance.
• Passed ROHS, PAHS and other testing.
• Anti-ultraviolet, sun protection.
Size INCH | I.D. mm |
mm | Length m/roll |
bar |
bar | g/m |
At23℃ | ||||||
13/64" | 5 | 10 | 100 | 12 | 40 | 76 |
1/4" | 6 | 11 | 100 | 12 | 36 | 87 |
5/16" | 8 | 13 | 100 | 10 | 30 | 105 |
3/8" | 10 | 15 | 100 | 10 | 30 | 130 |
1/2" | 12 | 18 | 100 | 9 | 27 | 185 |
5/8" | 16 | 22 | 50 | 8 | 24 | 230 |
3/4" | 19 | 25 | 50 | 6 | 18 | 270 |
7/8" | 22 | 28 | 50 | 5 | 15 | 305 |
1" | 25 | 31 | 50 | 5 | 15 | 340 |
1-1/4" | 32 | 40 | 40 | 4 | 12 | 590 |
1-1/2" | 38 | 46 | 40 | 4 | 12 | 690 |
1-3/4" | 45 | 56 | 30 | 4 | 12 | 1140 |
2" | 50 | 62 | 30 | 4 | 12 | 1380 |
2-1/2" | 64 | 78 | 20 | 4 | 12 | 2030 |
3" | 76 | 92 | 20 | 4 | 12 | 2750 |
